ABB机器人IRB1100

The most compact and fast robot everClass-leading performance for high-quality manufacturing Aimed at increasing manufacturing productivity, IRB 1100 provides up to 35% faster cycle times and best-in-class repeatability for high quality manufacturing. IRB 1100 consistently outperforms similar robots in terms of payload and position repeatability(RP)even whenunder space constraints. Indeed, IRB 1100 offers the highest payload for a robot of its class.

Compactand small footprint design ensures flexible installationCompared to the previous generation, the IRB 1100 robot design was optimized with a 10% smaller footprint and over 20% weight reduction for space-efficient installation in diverse environments, such as electronics manufacturing factories. Thesmallfootprintallows multiple robots to be deployed simultaneously in order to collaboratively perform automation operations, enabling more flexible handling for heavy-load operations with complex tools/end effectors.Further expanding ABB's small robot portfolio, IRB 1100 provides 35% increased productivity and up to 10% space savings.Powered by ABB's new OmniCoreM controller, IRB 1100 is equipped with advanced motion control capabilities, making it ideal for supporting rapid assembly, pick-and-place, and material handling applications.Rugged yet compact IP67rated The IRB 1100 has IP40 as standard protection and IP67 as option. The entire robot is designed to be IP67 compliant according to IEC60529-from base to wrist, which means that the electrical compartments are sealed against water and solid contaminants.Key benefits·Offers 35% faster cycle times for increased productivity·10% smaller footprint and over 20% weight reduction for easy installation. The highest payload for a robot of its class ·Equipped with up to 16I/O for more sophisticated/complex applications Main applications ·Assembly & Testing · Loading & Unloading · Screw driving · Rubber insertion· Polishing, grinding, buffing, deburring and sanding
